P/N | CA-1H8-00M1WN-00 |
---|---|
Series | View |
Model | View 31 TG |
CASE TYPE | Mid Tower |
Dimension (H x W x D) | 497 x 250 x 511 mm (19.5 x 9.8 x 20.1 inch) |
Net Weight | 9.9 kg / 21.8 lb |
SIDE PANEL | 4mm Tempered Glass x 2 (Left & Right) |
Color | Exterior & Interior : Black |
MATERIAL | SPCC |
COOLING SYSTEM | Front (intake) : 140 x 140 x 25 mm Riing LED Blue fan (1400rpm, 28dBA) x 1 (1000rpm, 22dBA with LNC) Rear (exhaust) : 140 x 140 x 25 mm Riing LED Blue fan (1400rpm, 28dBA) x 1 (1000rpm, 22dBA with LNC) |
Drive Bays -Accessible -Hidden |
-Accessible -Hidden 3 x 3.5’’ or 2.5’’ (HDD Cage) |
EXPANSION SLOTS | 8 + 2 |
MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
LCS Upgradable | Supports 1/2”、3/8”、1/4” water tube |
I/O Port | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
PSU | Standard PS2 PSU (optional) |
FAN SUPPORT | Front: 3 x 120mm , 2 x 140mm , 1 x 200mm Top: 3 x 120mm , 3 x 140mm , 2 x 200mm Rear: 1 x 120mm , 1 x 140mm Bottom: 2 x 120mm , 2 x 140mm |
RADIATOR SUPPORT | Front: 1 x 360mm , 1 x 280mm Top: 1 x 360mm , 1 x 280mm Rear: 1 x 120mm , 1 x 140mm Bottom: 1 x 120mm , 1 x 140mm |
CLEARANCE | CPU cooler height limitation: 180mm VGA length limitation: 278mm(with HDD rack) 420mm(without HDD rack) PSU length limitation: 180mm (With One Bottom Fan) 220mm (Without Bottom Fan) |
JAMSTVO: 36 mjeseci
